Wide Temp. VCTCXO/TCXO
Stable Operation in Extreme Temperatures — Taitien's Wide-Temperature VCTCXO & TCXO
Base stations in 5G communication often operate outdoors, requiring stability across a wide temperature range, from -40°C to +85°C, especially in extreme conditions. This necessitates communication equipment that can handle a broad operational temperature range and maintain high-level time synchronization, which is crucial for 5G network communications. The crystal oscillators used need to feature high frequency, low latency, and low phase noise. Taitien's wide-temperature range TCXO is designed with these requirements in mind, ensuring stable performance and high-quality signal delivery in high-speed networks, regardless of environmental challenges.
- High frequency stability up to ±50ppb
- Wide operating temperature range from -40˚C to 105˚C
- Power supply voltage options: 2.5V, 3.3V
- Low current consumption: <7.5mA @ CMOS
- Low phase noise: -156dBc/Hz @ 10kHz
- Standard frequencies: 10MHz, 19.2MHz, 20MHz
- Availability of Voltage-Controlled Temperature Compensated Crystal Oscillator (VC-TCXO) and Temperature Compensated Crystal Oscillator (TCXO) options
Related Categories
TL
5 x 3.2 mm VCTCXO
10 to 52 MHz
CMOS/Clipped Sine Wave
-142 dBc/Hz @ 1kHz
±0.1 ppm @ -40°C to +105°C
TS-K
7 x 5 mm VCTCXO
10 to 52 MHz
CMOS/Clipped Sine Wave
-148 dBc/Hz @ 1kHz
±0.1 ppm @ -40°C to +105°C
TT-K
7 x 5 mm VCTCXO
10 to 52 MHz
CMOS/Clipped Sine Wave
-148 dBc/Hz @ 1kHz
±0.1 ppm @ -40°C to +105°C
